| Working Width | 800mm/1000mm/1300mm | |
| Working Thickness | 1-80mm | |
| Conveyor Speed | 1-8m/min(frequency control) | |
| Sanding Belt Speed | 2.2-11m/s(frequency control) | |
| Grinding Speed | 9-18r/s(frequency control) | |
| Revolution Speed | 9-19r/min(frequency control) | |
| Rated Voltage | AC 380V/50Hz | |
| MAX.POWER | Vacuum | 32KW/40KW/48KW(excluding dust collector) |
| Magnetic | 21KW/25KW/33KW(excluding dust collector) | |
| Compressed Air | 0.6-0.8Mpa | |
| Weight | 2200kg/3100kg/3700kg | |
1Surface Brushing, Slag And Burrs Removing
2Uniform Rounding Of Inner And Outer Contours
3Strong Adsorption Force, Suitable For Smaller Workpieces
4Automatic compensation of grinding force
5Memory Of Process Parameters
6Automatic Cleaning Of Adsorption Chamber
7Intelligent Perception Protection
8Abrasive Replacement Reminding
